BLACKMAGIC DESIGN 4K G2 Micro Studio Camera (CINSTUDMFT/UHD/MRG2)

Be the first to review the product Write a Review
$995.00
$925.65
BLACKMAGIC DESIGN 4K G2 Micro Studio Camera (CINSTUDMFT/UHD/MRG2)
BLACKMAGIC DESIGN 4K G2 Micro Studio Camera (CINSTUDMFT/UHD/MRG2)
BLACKMAGIC DESIGN 4K G2 Micro Studio Camera (CINSTUDMFT/UHD/MRG2)
BLACKMAGIC DESIGN 4K G2 Micro Studio Camera (CINSTUDMFT/UHD/MRG2)
BLACKMAGIC DESIGN 4K G2 Micro Studio Camera (CINSTUDMFT/UHD/MRG2)
BLACKMAGIC DESIGN 4K G2 Micro Studio Camera (CINSTUDMFT/UHD/MRG2)
SKU:
BLMD-CINSTUDMFT/UHD/MRG2
UPC:
9338716008630
MPN:
CINSTUDMFT/UHD/MRG2
Current Stock:
FREE Standard Delivery
30-Day Easy Returns
Secure Ordering

Frequently Bought Together:

Inc. Tax
Ex. Tax

Description

Features of BLACKMAGIC DESIGN 4K G2 Micro CINSTUDMFT-UHD-MRG2

  • UHD 4K Resolutions up to 3840 x 2160p60
  • Active Micro Four Thirds Lens Mount
  • 12G-SDI Video Input/Output, HDMI Output
  • 13-Stop Dynamic Range, Compact Design
  • Camera Control via SDI, HDMI, or USB
  • Program and Talkback over SDI, Tally
  • Built-In Color Corrector
  • Canon LP-E6 Battery Slot

Product Info for BLACKMAGIC DESIGN 4K G2 Micro CINSTUDMFT-UHD-MRG2

The BLACKMAGIC DESIGN 4K G2 Micro Studio Camera is an amazing, broadcast quality live production camera in a tiny body. The Four Thirds sensor has 13 stops of dynamic range, incredible low light performance and produces stunning Ultra HD images in all lighting conditions. 12G-SDI Micro BNC connectors support 10-bit uncompressed video up to 2160p60 and 2 channel audio on the output.

The input supports tally, camera control, control of the built-in color corrector plus lens control, from an ATEM switcher. Or when using an ATEM Mini switcher, the HDMI connector will output 1080 and support all control features. Plus it's even a Hollywood quality cinema camera because it can record Blackmagic RAW to external USB-C drives. With multiple mounting points, place Blackmagic Micro Studio Camera 4K G2 where no other camera will go!


GritrOutdoors is an authorized Blackmagic Design dealer

Details

Activity:
Video Recording
Color:
Black
Model:
4K G2
Product Type:
Studio Cameras
SALE:
On Sale
On Sale:
On Sale Up to 10% off

Specification

Camera Features
Effective Sensor Size, mm 17.78mm x 10mm (Four Thirds)
Lens Mount Active MFT Mount
Lens Control Iris, focus, zoom on supported lenses
Dynamic Range 13 Stops
Dual Native ISO 0dB and 18dB gain
Sensitivity at 0dB Gain f11 with 2160p59.94.
f12 with 2160p50.
at 2,000 lux with 89.9% reflectance
Signal to Noise Ratio 63dB for 2160p
Shooting Resolutions 3840 x 2160 (Ultra HD) up to 60 fps
Frame Rates 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 frames per second.
Off-speed frame rates up to 60 fps in Ultra HD
Focus Auto focus available using compatible lenses
Mounting Options 1 x 1/4 inch (top),
3 x 1/4 inch (bottom)
Connections
SDI Video Inputs 1
SDI Video Outputs 1
SDI Rates 3G, 6G, 12G
HDMI 2.0 Video Outputs 1
HDMI Video Outputs 1 x HDMI Type A output.
HDMI output is always HD, up to 1080p60
Analog Audio Input 1 x 3.5mm Stereo Input. Can also be used for Timecode input
Reference Inputs Program SDI Input on camera
SDI Audio Output 2 channels of program audio embedded in 3G/6G/12G-SDI
HDMI Audio Outputs 2 channels 48 kHz and 24‑bit
Remote Control Remote camera control over SDI, HDMI or USB Ethernet with suitable adapter
Computer Interface 1 x USB Type‑C 3.1 Gen 1 (up to 5Gb/s) expansion ports for external recording
and focus / zoom demand connection. Software updates using USB‑C Port
Audio
Microphone Integrated stereo microphone
Built in Speaker None
Standards
SD Video Standards None
HD Video Standards 1080p23.98, 1080p24, 1080p25, 1080p29.97,
1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
SDI Compliance SMPTE 292M, SMPTE 424M, SMPTE 425M level A and B,
SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1 and SMPTE 2082‑10
SDI Audio Sampling Television standard sample rate of 48 kHz and 24‑bit
Media
Media 1 x USB-C 3.1 Gen 1 expansion ports for external media for recording Blackmagic RAW
Media Format Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems
Supported Codecs
Codecs Blackmagic RAW Constant Bitrate 3:1,
Blackmagic RAW Constant Bitrate 5:1,
Blackmagic RAW Constant Bitrate 8:1,
Blackmagic RAW Constant Bitrate 12:1,
Blackmagic RAW Constant Quality Q0,
Blackmagic RAW Constant Quality Q1,
Blackmagic RAW Constant Quality Q3,
Blackmagic RAW Constant Quality Q5
Storage Features
Storage Type 1 x USB‑C 3.1 Gen 1 expansion ports for external media
Recording Formats Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3 and Q5 in
Ultra HD 3840 x 2160 at the selected frame rate
Storage Rates Storage rates based on 30 frames per second.

3840 x 2160 (Ultra HD)
Blackmagic RAW 3:1 - 127 MB/s
Blackmagic RAW 5:1 - 77 MB/s
Blackmagic RAW 8:1 - 48 MB/s
Blackmagic RAW 12:1 - 32 MB/s
Blackmagic RAW Q0 - 96 to 190 MB/s
Blackmagic RAW Q1 - 64 to 153 MB/s
Blackmagic RAW Q3 - 43 to 109 MB/s
Blackmagic RAW Q5 - 26 to 64 MB/s
Control
5 Control 5 control buttons including Set, Up, Down, Menu, and Power
External Control Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling your camera and lens from tripod handles.

Blackmagic Control Protocol over SDI and HDMI for external control when used with
a compatible ATEM switcher with ATEM Software Control or ATEM Camera Control Panel.
Includes control of some camera settings, focus, iris and zoom with compatible lenses,
color corrector, tally and record start and stop to external media via USB expansion port.

Camera Control REST API over USB Ethernet for external control via HTTP when
used with REST client applications such as Postman
Network Management
NTP Network time protocol support allows you to sync the time on your camera,
whenever connected to a network with any NTP server of your choice
Web Media Manager Using a browser connected over Ethernet, web media manager allows you to access,
browse, download and delete files from any drive connected to the camera
FTP Download files from any drive attached to your camera using FTP.
SMB File sharing using SMB
Software
Software Included Blackmagic Camera Setup for Mac and Windows
Operating Systems Mac 12.0 Monterey,
Mac 13.0 Ventura or later,
Windows 10, 64-bit.
Windows 11, 64-bit
Power Requirements
Power Supply 1 x External 12V DC 36W power supply
Power Inputs 1 x 12V DC locking 5.5 mm barrel connector
Power Usage 18 ‑ 25 W
Environmental Specifications
Operating Temperature 0° to 40°C (32° to 104°F)
Storage Temperature -20° to 45°C (-4° to 113°F)
Relative Humidity 0% to 90% non-condensing
Physical Specifications
Length, in 3.3"
Width, in 2.74"
Height, in 2.6"
Weight, oz 10.58
What's Included
Included Blackmagic Micro Studio Camera 4K G2
Turret dust cap
External 12V DC power supply with locking connector and international socket adapters for most countries
Welcome wallet with QR code for software download
