Description
Features of STEINER Cinder 3X Thermal Optic with Mount 9501
- Rugged, durable design
- Shutterless imaging
- Includes picture-in-picture, up to 4x digital zoom
- Seamless integration with Google Maps for location tracking and geotagging
- Passive range estimation
- 50 Hz frame rate ideal for fast-moving targets
- Video recording with 8 GB of internal memory
- Fully configurable from smartphone, or via onboard menus
- High quality, full-color OLED display and large objective lens results in premium quality image
- Easy-to-change batteries
Product Info for STEINER Cinder 3X Thermal Optic with Mount 9501
Steiner is one of the largest manufacturers of high-quality optics in the world. The Cinder Thermal Scope is designed for use in day, night, and poor weather conditions (fog, smog, dust). In addition to an extensive on-board feature set including multiple color palettes, photo and video storage, and electronic zoom, this cutting edge device runs a custom Android OS allowing wireless connection to smartphones, tablets, and the Cloud.
With a compact design and low power consumption, the Cinder is particularly well suited for hunting or other outdoor activities, including detecting items through a variety of obstacles (bushes, grass, foliage).
GritrOutdoors is an authorized Steiner dealer
Details
Activity: |
Hunting |
Color: |
Black/Green |
Magnification: |
3x |
Model: |
Cinder |
Product Type: |
Thermal Vision Scopes |
Specification
| Detector | |
| Detector Type | 320 x 240, 12 μm pixels |
| Spectral Band | Long wave infrared 8-14 μm |
| NETD | 60 mK |
| Optical Characteristics | |
| Focal Length | 25 mm, 3x optical magnification |
| Focusable | Yes |
| Eye Relief | 40 mm, adjustable diopter |
| Field of View | 8.8° (H) x 6.7° (V) |
| Display | |
| Microdisplay | Full color OLED, SVGA (800 x 600) |
| Imaging | |
| Frame Rate | 50 Hz |
| Digital Zoom | 1-4x |
| Color Palettes | White Hot, Black Hot, Blues, Davfire, Fire, Greens, Jet, Reds, Viridis, Dusk, Teals, Inferno |
| Photo | Yes |
| Video | Yes |
| Recoil-activated video | Yes |
| Memory | Internal 8 GB memory |
| Shutterless NUC | Yes |
| Picture-in-Picture a Zoom | Yes |
| Advanced Image a Processing Algorithms | Yes |
| Thermal Modes | Full, Gradient, Outline |
| Selective Coloring | Yes |
| Stadiametric Rangefinder | Both iOS and Android |
| Wi-Fi | Wi-Fi 802.11 b/g/n, H.264 and MPEG4 compression |
| Geotagging | Virtual waypoints, Google Maps integration |
| Power Supply | |
| Battery Type | (1) User-replaceable rechargeable 18650
battery or (2) non-rechargeable CR123A batteries |
| Battery Operating Time | >3 hours |
| Interface | |
| Video Out | Via streaming to app |
| Environmental | |
| Operating Temperature | -20°C to +50°C |
| Water Resistance | IP64 |
| Physical Characteristics | |
| Dimensions, mm | 203 x 91 x 66 |
| Weight, g | 716 (with 2 CR123A batteries) |
