AIDA HD-100A Full HD HDMI Camera HD-100A


AIDA HD-100A Full HD HDMI Camera (HD-100A)

(No reviews yet) Write a Review
  • AIDA HD-100A Full HD HDMI Camera (HD-100A)
  • AIDA HD-100A Full HD HDMI Camera (HD-100A)
  • AIDA HD-100A Full HD HDMI Camera (HD-100A)
Free Standard Delivery
FREE Standard Delivery
30-Day Easy Returns
30-Day Easy Returns
Secure Ordering
Secure Ordering
Size Chart


Features of AIDA HD-100A Full HD HDMI Camera HD-100A

  • Full HD Progressive Scan sensor captures sharp and vivid color under different light conditions
  • Advanced digital image processor provides vivid and detailed images by utilizing WDR, White Balance, and Noise Reduction
  • Motion-compensated temporal noise reduction filter leads to effective noise reduction for motion video without blur
  • HDMI seamless video performance
  • Black Level Set-up provides the better color transition from digital to analog
  • Auto White Balance and shutter speed provides the optimized performance in a variety of situations
  • Interchangeable lens design makes it compatible with auto-iris CS and C mount lenses
  • Built-in OSD controls for customizable image settings
  • Versatile, compact, and rugged design
  • With TRS Stereo Audio Input for embedded audio over HDMI

Product Info for AIDA HD-100A Full HD HDMI Camera HD-100A

The AIDA HD-100A Full HD HDMI Camera is a cost-friendly Full-HD Broadcast Camera designed for any level of production. Packed with a 1/3" progressive CMOS image sensor and interchangeable lens, the HD-100A provides clear, crisp HD video suitable for any existing workflow. The HD-100A offers versatile Full-HD resolutions including drop-frames, adjustable video settings, and a small rugged form factor, making it perfect anywhere you need it to be.

GritrOutdoors is an authorized Aida dealer

View AllClose

Size Chart/Specs

Image Sensor 1/3 inch Progressive CMOS
Sensor Size Diagonal 7.2mm
Effective Pixels Horizontal: 1920, Vertical: 1080
Pixel Size 2.75 μm x 2.75 μm
Resolution 1080p & 1080i: 1920 x 1080
720p & 720i: 1280 x 720
Resolution/Rate 1080 60p/59.94p/50p/30p/29.97p/25p/24p
1080 60i/59.94i/50i
720 60p/59.94p/50p
Output HDMI 1.3a
Color Space 4:2:2 (YCbCr) 10bit
Min. Illumination 0.2Lux (Day), 0.1Lux (Night), 0.005Lux (Slow Shutter ON)
White Balance Auto & Manual (9,000 K - 11,000 K)
Lens C/CS Mount (Default 4mm HD Lens)
Input 3.5mm TRS Stereo Mic-in & Line in over I/O Cable
Sample Rate 16/24/32 Bits
Camera Control RS-485 VISCA, OSD Button
Operation Temp 32° F - 104° F
Dimensions, in 1.53" x 1.53" x 1.99" (with default 4mm Lens)
Weight, lbs 0.39 (with default 4mm Lens)
Power 6W at 12VDC (+9 - +15VDC)
