Description
Features of AIDA HD-100A Full HD HDMI Camera HD-100A
- Full HD Progressive Scan sensor captures sharp and vivid color under different light conditions
- Advanced digital image processor provides vivid and detailed images by utilizing WDR, White Balance, and Noise Reduction
- Motion-compensated temporal noise reduction filter leads to effective noise reduction for motion video without blur
- HDMI seamless video performance
- Black Level Set-up provides the better color transition from digital to analog
- Auto White Balance and shutter speed provides the optimized performance in a variety of situations
- Interchangeable lens design makes it compatible with auto-iris CS and C mount lenses
- Built-in OSD controls for customizable image settings
- Versatile, compact, and rugged design
- With TRS Stereo Audio Input for embedded audio over HDMI
Product Info for AIDA HD-100A Full HD HDMI Camera HD-100A
The AIDA HD-100A Full HD HDMI Camera is a cost-friendly Full-HD Broadcast Camera designed for any level of production. Packed with a 1/3" progressive CMOS image sensor and interchangeable lens, the HD-100A provides clear, crisp HD video suitable for any existing workflow. The HD-100A offers versatile Full-HD resolutions including drop-frames, adjustable video settings, and a small rugged form factor, making it perfect anywhere you need it to be.
GritrOutdoors is an authorized Aida dealer
Details
Activity: |
Video Recording |
Color: |
Black |
Model: |
HD-100A |
Product Type: |
Video Cameras |
Specification
| Video | |
| Image Sensor | 1/3 inch Progressive CMOS |
| Sensor Size | Diagonal 7.2mm |
| Effective Pixels | Horizontal: 1920, Vertical: 1080 |
| Pixel Size | 2.75 μm x 2.75 μm |
| Resolution | 1080p & 1080i: 1920 x 1080 720p & 720i: 1280 x 720 |
| Resolution/Rate | 1080 60p/59.94p/50p/30p/29.97p/25p/24p 1080 60i/59.94i/50i 720 60p/59.94p/50p |
| Output | HDMI 1.3a |
| Color Space | 4:2:2 (YCbCr) 10bit |
| Min. Illumination | 0.2Lux (Day), 0.1Lux (Night), 0.005Lux (Slow Shutter ON) |
| White Balance | Auto & Manual (9,000 K - 11,000 K) |
| Lens | |
| Lens | C/CS Mount (Default 4mm HD Lens) |
| Audio | |
| Input | 3.5mm TRS Stereo Mic-in & Line in over I/O Cable |
| Sample Rate | 16/24/32 Bits |
| Physical | |
| Camera Control | RS-485 VISCA, OSD Button |
| Operation Temp | 32° F - 104° F |
| Dimensions, in | 1.53" x 1.53" x 1.99" (with default 4mm Lens) |
| Weight, lbs | 0.39 (with default 4mm Lens) |
| Power | 6W at 12VDC (+9 - +15VDC) |
