Description
Features of Eotech XP S2 Holographic Sight XPS2-1
- Compact, lightweight holographic weapon sight with 1x magnification
- Uses laser light to illuminate holographic red reticle projected on target plane
- Improves target acquisition, boosts accuracy, and increases control
Product Info for Eotech XP S2 Holographic Sight XPS2-1
The EOTECH XPS 2-1 Holographic Weapon Sight, 1 MOA dot Ret., CR-123 Bat. (XPS2-1) is shortest model sight yet! This sight is smaller than the former N-cell battery sight (511/551) and runs on a single 123 battery. It also has a longer battery life than the N-cell style sights.
Smaller, lighter and always fast the Eotech XPS2-1 features the new single battery configuration. Also this Holographic Weapon Sight allows more rail space than ever, leaving more room for rear iron sights or NV mount.
The battery compartment was completely redesigned to accommodate a single CR123A battery - an easy to open cover is held in place by a tethered o-ring, and the compartment is elevated so it hovers over the Delta Ring.
Designed for today's modern battlefield, the Eotech sight XPS 2-1 is submersible to a depth of 33 feet, and the Picatinny/Weaver mount is repeatable to 2 MOA after re-mounting. The rear window is a 3/16" thick shatterproof laminate with anti-glare and scratch resistant coatings, and the front lens is 1/8" solid glass. Because the optical system is based upon transmission holography, parallax error is not an issue - this is an excellent feature that can save your hams when the mayonnaise hits the fan.
WARNING: This Holographic Weapon Sight is controlled under the U.S. International Traffic in Arms Regulations (ITAR) and may not be exported without proper authorization by the U.S. Department of State.
GritrOutdoors is an authorized Eotech dealer
Details
Activity: |
Shooting |
Base Fit: |
Picatinny |
Color: |
Black |
Model: |
XP S2 |
Product Type: |
Reflex Sights |
Reticle Size: |
1 MOA Dot |
Specification
| Operation | |
| Optics | Transmission holography |
| Magnification | 1x |
| Eye Relief | Unlimited |
| Size (L x W x H), in | 3.8" x 2.1" x 2.5" |
| Weight, | 9.0 |
| Water Resistant | Submersible to 10 ft (3m) |
| Sealing | Fog resistant internal optics |
| Color/Finish | Non-reflective black |
| Adjustment (per Click), in @ 100yds | 1/2" (0.5 MOA) |
| Adjustment Range | +/- 40 MOA travel |
| Mount | 1" Weaver or MIL-STD 1913 rail |
| Display Window | |
| Optical Surfaces | Anti-Reflection coating on external surfaces |
| Window Dimensions, in. | 1.20" x 0.85" |
| Front Window Material | Glass 1/8" (3.17mm) thick |
| Rear Window Material | Laminate 3/16" (4.76mm) thick |
| Field of View 100 yds | 30 yds (28m) at a 3" eye relief |
| Reticle Options | Single 1 MOA aiming dot (no outer circle) |
| Electrical | |
| Power Source | One (1) 123 lithium battery |
| Battery Life | Approximately 600 continuous hours at nominal setting 12 at room temp |
| Brightness Settings | 20 settings with scrolling feature |
| Auto Battery Check Indicator | Flashing reticle upon start-up |
| Auto Shut-down | At 8 hrs- programmable to 4 hrs |
