Description
Features of LEUPOLD Mark 5HD 2-10x30 FFP PR-1MOA Riflescope 179704
- A versatile 5:1 zoom ratio gives you 5 times more magnification at high power
- Professional-Grade Optical System offers unmatched light transmission
- First Focal Plane
- Custom Dial System (CDS) gives you the ability to customize your turret
- Lightwieght Aluminium Housing
- ZeroLock system eliminates accidental dial movement
- ZeroStop system creates a backstop when returning the dial back to zero
- The side focus adjusts the scope's parallax
- The removable, low-profile throw lever makes changing magnifications quick and easy
- Modern waterproof and fogproof technology
Product Info for LEUPOLD Mark 5HD 2-10x30 FFP PR-1MOA Riflescope 179704
The Mark 5HD 2-10x30mm exemplifies military tradition. Created as an evolution of the riflescopes used on the MK12 SPR, this modern optic extends the limits of tactical carbines. A three-turn dial crowns its elevation turret, providing 34.9 MILs of adjustment in 0.1 MIL increments and Leupold patented ZeroLock ensures the dial won't move when knocked around. This mid-range scope is as bomb-proof as it gets, but it's also incredibly lightweight and accurate. With its first focal plane reticle, 2-10 magnification range, and side focus, engaging in close-quarters combat is just as easy as identifying threats from a distance.
GritrOutdoors is an authorized Leupold dealer
Details
Activity: |
Shooting |
Color: |
Black |
Finish: |
Matte |
Firearm Fit: |
Rifles |
Magnification: |
2-10x |
Model: |
Mark 5HD |
Product Type: |
Riflescopes |
Tube Size: |
30mm |
Objective Size: |
30mm |
Specification
|
Elevation Adjustment Value per Click |
1/4MOA |
|
Elevation Adjustment Range (MOA) |
165 |
|
Elevation Adjustment Range (MIL) |
48 |
|
Elevation Adjustment Range (cm @ 100m) |
480 |
|
Elevation Adjustment Per Revolution |
25 MOA |
|
Elevation Dial Travel Limit |
71.5MOA |
|
Windage Adjustment Value per Click |
1/4MOA |
|
Windage Adjustment Range (MOA) |
80 |
|
Windage Adjustment Range (MIL) |
23 |
|
Windage Adjustment Range (cm @ 100m) |
230 |
|
Windage Adjustment Per Revolution |
24 MOA |
|
Magnification Max |
10 |
|
Magnification Min |
2 |
|
Objective Lens Diameter (mm) |
30 |
|
Linear FOV Low Mag (ft@100yds) |
52.9 |
|
Linear FOV High Mag (ft@100yds) |
10.5 |
|
Angular FOV Low Mag (Degrees) |
10 |
|
Angular FOV High Mag (Degrees) |
2 |
|
Eye Relief Low Mag (in) |
3.6 |
|
Eye Relief High Mag (in) |
3.7 |
|
Minimum Parallax-Free Distance (yd) |
40 |
|
Adjustable Objective |
No |
|
Elevation Adjustment Type |
M1C3 |
|
Locking Dial |
Yes |
|
Revolution Indicator |
Yes |
|
Rezero Type |
Set Screw |
|
Windage Adjustment Type |
Capped |
|
Custom Dial System (CDS) |
No |
|
BDC Dial Included |
No |
|
Reticle Type |
First Focal Plane |
|
Reticle |
FFP PR-1MOA |
|
Magnification Type |
Variable |
|
Illuminated |
No |
|
Nightvision Compatible Illumination |
No |
|
Daylight Bright Illumination |
No |
|
Motion Sensor Technology (MST) |
No |
|
Electronic Reticle Level |
No |
|
Guard-ion Lens Coating |
No |
|
Weight (oz) |
24 |
