Description
Features of BLACKVUE DR770X-2CH IR LTE DashCam DR770X-2CH-IR-LTE-64
- Reliable and high-resolution cloud dash cam
- Improved Sony STARVIS 2.1MP image sensor with night vision
- Resolution: Full HD with smooth 60 fps
- Memory card: High Quality 64GB microSD
- With an inconspicuous interior camera: films the driver and passengers
- Integrated LTE extension: enables cloud access to dash cam anytime and anywhere
- Convenient WiFi function for BlackVue App
- Parking mode monitoring: intelligent power supply via vehicle battery
- Integrated GPS for map and speed information
- Integrated microphone and speaker
Product Info for BLACKVUE DR770X-2CH IR LTE DashCam DR770X-2CH-IR-LTE-64
With the infrared Interior-Facing feature, the BLACKVUE DR770X-2CH IR LTE Dual Lens Cloud Dash Cam can monitor what's going on inside the vehicle day or night, including the actions of the driver and passengers. This can be particularly useful for parents of teenage drivers, ride-sharing services, and company vehicles. In addition to the interior cabin view, these dash cams can also be positioned to capture what's out the rearview window, a best of both worlds bonus over other camera systems.
The DR770X-2CH-IR-LTE is the upgraded version of the DR750X series, offering 60FPS Full HD video capture and superior day and night detail. This dash cam is loaded with top-tier features like parking surveillance, seamless app pairing, LTE cloud connectivity, Wi-Fi, GPS, and Bluetooth, with options for a rear or interior camera. Plus, it even includes a BlackVue LTE SIM card. With LTE SIM activated, you're connected to your dash cam 24/7. You can monitor your vehicle with remote live view, receive alerts when motion or impacts are detected, check current and event map locations, utilize Hotspot functionality, and more!
Sony STARVIS sensor
The DR770X front camera records Full HD video at 1080p and 60 FPS in a 139-degree wide angle. 60 frames/second means videos look more lifelike and the dash cam is better able to capture detail in fast-moving objects, such as license plates, thanks to reduced motion blur. With the Sony STARVIS image sensor, you get impressive image clarity day and night.
Indoor camera with night vision
The camera films the driver and passengers to monitor the interior. With the Sony STARVIS image sensor with infrared LEDs, you get impressive image clarity in Full HD day and night. The IR camera is connected to the front camera using a coax cable (1.5m).
Seamless pairing
Just connect to your dash cam without leaving the app. Turn on the dash cam and connect via the BlackVue app and follow the instructions. Whether you want to browse your dash cam's files and settings, or connect your dash cam to the cloud, the app makes everything easy and intuitive.
WiFi + 4G LTE module
You can connect to your BlackVue using a smartphone or tablet via Wi-Fi.
LTE allows you to access your BlackVue via the cloud from anywhere, anytime. You can live view, backup videos (or even automatically upload event recordings to cloud), receive push notifications, show GPS location, etc.
Insert a SIM card into the tray, turn on the BlackVue, then follow the steps in the Connect to Cloud menu of the BlackVue app. 1GB, 3GB and 5GB plans available. Payable monthly. Cancellable at any time.
Cloud features
Over the Cloud is all about using your dashcam to keep you and your car connected.
With it, you can connect to your BlackVue anytime, anywhere in the world. Enjoy remote live view and push notifications to your phone. Back up important videos to the cloud remotely. Play videos from dash cam or cloud storage and download them from anywhere. Enjoy two-way voice communication with the driver from the app via the dashcam's built-in speaker and microphone.
High quality microSD
Every BlackVue dashcam comes with an original BlackVue microSD card. Blackvue tests their cards extensively before selecting them for inclusion in their products to ensure their performance is good and degrades as little as possible over time.
Easy video management with BlackVue Viewer
BlackVue Viewer (WINDOWS/MAC) is free to download and use. With it, you can easily change your BlackVue configuration settings and review recorded videos.
Videos are displayed here chronologically and by type (Normal/Event/Parking) so you can quickly identify and archive important footage. You can also export video segments, remove audio, or export screenshots.
With the BlackVue app, you can connect to your dash cam via WiFi to retrieve video on the spot.
Parking mode support
In parking mode, the dash cam monitors your vehicle while you're away and records video when it detects movement or an impact. The connection cable for connecting to the vehicle battery is already included (alternatively: Power Magic Pro or Power Magic Battery Pack).
The dash cam automatically switches to parking mode when the ignition is switched off. Voltage shutdown and timer can be set in the BlackVue App.
GPS functions
Log the speed and position of your videos.
Speed: Speed data is overlaid on the video (can be turned off in settings). You can choose whether this should be displayed in Km/h or Mph.
Position: You can visualize the location of your vehicle on the BlackVue Viewer map during video playback.
GritrOutdoors is an authorized Blackvue dealer
Details
Activity: |
Automotive |
Color: |
Black |
Model: |
DR770X-2CH IR LTE |
Product Type: |
Dash Cams |
Specification
| Model Name | DR770X-2CH IR LTE |
| Memory Capacity | 64GB |
| Channel | 2CH |
| Highlights | Built-in 4G LTE, Sony STARVIS image sensors, Infrared (IR) Interior Camera |
| Product Dimensions | Front: Black / Width 137.6 mm x Height 43 mm / 161 g Interior: Black / Width 67.4 mm x Height 25 mm / 27 g |
| Rear Camera Connection | Coaxial cable |
| Memory Support | microSD card up to 256GB |
| Recording Modes | Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected) * When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode |
| Parking Mode | Yes (hardwiring cable included) |
| Parking Mode Event Voice Notifications | Yes |
| Imaging Sensor | Front: Sony STARVIS CMOS Sensor (Approx. 2.1 M Pixel) Interior: Sony STARVIS CMOS Sensor (Approx. 2.1 M Pixel) |
| Viewing Angle | Front: Diagonal 139°, Horizontal 116°, Vertical 61° Interior: Diagonal 180°, Horizontal 150°, Vertical 93° |
| Resolution Frame Rate | Front / Interior Full HD (1920×1080) @60fps – Full HD (1920×1080) @30fps * Frame rate may vary during Wi-Fi streaming |
| Video Codec | H.264 (AVC) |
| Image Quality and Bitrate Front/Rear | Highest (Extreme): 25+10 Mbps Highest: 12+10 Mbps High: 10+8 Mbps Normal: 8+6 Mbps |
| Format Free | Yes (Adaptive) |
| Event File Overwrite Protection | Yes (up to 50) |
| SD Card Failure Alert | Yes |
| Scheduled Reboot | Yes |
| Video File Extension | MP4 |
| Wi-Fi | Built-in (802.11n (2.4~2.4835 GHz)) |
| Cloud Compatible | Yes |
| GPS | Build-in |
| Microphone | Built-in |
| Speaker | Built-in |
| Impact Sensor | 3-Axis Acceleration Sensor |
| LED Indicators | Front: REC LED, GPS LED, B/W /L LED, Front Security LED Interior: Interior Security LED |
| Rear Camera IR Illumination | 940 nm (4 Infrared (IR) LEDs) |
| Button | Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings |
| Operation Temperature | -20°C - 70°C (-4°F - 158°F) |
| Storage Temperature | -20°C - 70°C (-4°F - 158°F) |
| High Temp Cut Off | Approx. 80 °C (176 °F) |
| Backup Battery | Built-in supercapacitor |
| Input Power | DC 12V-24V (3 pole DC Plug(Ø3.5 x Ø1.1) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
| Power Consumption Hour | Normal Mode (GPS On/Cloud On): Avg. 470mA/12V Normal Mode (GPS On/Cloud Off): Avg. 410mA/12V Parking Mode (GPS Off/Cloud On): Avg. 370mA/12V Parking Mode (GPS Off/Cloud Off): Avg. 310mA/12V * Approx. 40mA increase in current when IR LEDs are ON * Actual power consumption may vary depending on use conditions and environment * Model DR770X-2CH IR LTE should be used only in circuits that satisfy Limited Power Source (Maximum power consumption is to be less than 100 VA or 8 A) |
| Certifications | Front: FCC, ISED, CE, UKCA, RCM, Telec, RoHS, WEEE, KC Interior: FCC, ISED, CE, UKCA, RCM, RoHS, WEEE, KC |
| Software | BlackVue Viewer * Windows 7 or higher, Mac Sierra OS X (10.12) or higher BlackVue Web Viewer * Chrome 71 or higher, Safari 13.0 or higher |
| Application | BlackVue Application * Android 8.0 or higher, iOS 13.0 or higher |
| Others | Built-in 4G LTE module compatible with Nano-SIM Frequency Bands: North America (NA version): B2, B4, B12 | Australia (AU version): B3, B5 | Japan (JP version): B1, B3, B18, B19 | Europe/Rest of world (GL version): B1, B3, B7, B20 |
| Bluetooth | Built-in (V2.1+EDR/4.2) |
| LTE | Built-in (SIM card not included) |
