Description
Features of HAWKE Airmax 30 FFP SF 6-24x50 AMX IR Riflescope 13352
- Capped Target Turrets
- First Focal Plane
- 30mm Mono-Tube Chassis
- Wide Angle
- Side Focus
- Side Wheel (Removable)
- Illumination
- 16 Layer Fully Multi-Coated Lenses
- High Torque Zoom Ring
- Fast Focus Eyebell
Product Info for HAWKE Airmax 30 FFP SF 6-24x50 AMX IR Riflescope 13352
Designed for use with air rifles, the HAWKE Airmax 30 FFP SF 6-24x50 Riflescope features a large 50mm objective that admits ample light for a bright image, even in lower-light conditions, and a wide magnification range for long shots. The optics bear 16 layers of anti-reflection coatings to increase image resolution, clarity, and brightness. Located in the first focal plane is an AMX IR reticle, which provides multiple aiming points on all axes and offers six red brightness levels, with off positions in between.
Capped, resettable target turrets adjust at 1/10 MRAD per click, with a total elevation and windage adjustment range of 17 MRAD for precise impact point correction. A side parallax adjustment with removable wheel allows correction of parallax errors from 10 yards to infinity. The scope has a lightweight and durable anodized aluminum housing with a 30mm maintube and is nitrogen filled and O-ring sealed to be waterproof and fogproof.
GritrOutdoors is an authorized Hawke dealer
Details
Activity: |
Hunting |
Color: |
Black |
Finish: |
Matte |
Firearm Fit: |
Rifles |
Magnification: |
6-24x |
Model: |
Airmax 30 |
Product Type: |
Riflescopes |
Submodel: |
FFP |
Tube Size: |
30mm |
Specification
| Magnification | 6-24x |
| Objective Diameter, mm | 50 |
| Field of View, ft @ 100yds | 21.0-5.2 |
| Angular Field of View, deg | 4-1° |
| Eye Relief, in | 3.5" |
| Exit Pupil, in | 0.33-0.08" |
| Parallax | Side Focus |
| Optical System | System H2 |
| Scope Tube, mm | 30 |
| PX/Focus (Error free from) | 10 yds to infinity |
| Turret Caps | Yes |
| Click Value | 1/10 MRAD |
| Elevation Turret Clicks (max) | 17 MRAD |
| Windage Turret Clicks (max) | 17 MRAD |
| Reticle | AMX IR |
| Illumination | 6 Levels with Off Positions In-between - Red |
| Ocular Type | Fast Focus |
| Power Selector | Rubber Coated Posi-Grip |
| Lens Coating | Fully Multi-Coated - 16 Layers |
| Focal Plane | FFP (First Focal Plane) |
| Length, in | 14.9" |
| Weight, oz | 27 |
