Description
Features of BLACKVUE DR770X-2CH LTE Dash Cam DR770X-2CH-LTE
- Reliable and high-resolution cloud dash cam
- Improved Sony STARVIS 2.1MP image sensor with night vision
- Resolution: Full HD with smooth 60 fps
- Memory Card: High Quality 64GB/256 microSD
- With an inconspicuous interior camera: films the driver and passengers
- Integrated LTE extension: enables cloud access to dash cam anytime and anywhere
- Convenient WiFi function for BlackVue App
- Parking mode monitoring: intelligent power supply via vehicle battery
- Integrated GPS for map and speed information
- Integrated microphone and speaker
Product Info for BLACKVUE DR770X-2CH LTE Dash Cam DR770X-2CH-LTE
The DR770X-2CH LTE Dual Lens Cloud Dash Cam is the latest upgrade over the previous DR750X-LTE series. This Front + Rear dual channel setup provides a near 360-degree bubble around your vehicle, ensuring incidents while driving and while parked are captured no matter the circumstance. This is a great option for parents of teen drivers, company vehicles, and daily commute vehicles.
At 60FPS Full HD, the DR770X is capable of capturing an unprecedented level of detail in both day and night. The DR770X also comes loaded with all the additional features you'd expect from a top tier dash cam, such as parking surveillance mode, seamless app pairing, optional LTE cloud connectivity, built-in Wi-Fi, GPS, and Bluetooth, as well as your choice of a secondary rear, or interior camera.
Best of all, this dash camera even comes with a BlackVue LTE SIM card included. With LTE SIM activated, you're connected to your dash cam 24/7. You can monitor your vehicle with remote live view, receive alerts when motion or impacts are detected, check current and event map locations, utilize Hotspot functionality, and more!
GritrOutdoors is an authorized Blackvue dealer
Details
Activity: |
Automotive |
Color: |
Black |
Product Type: |
Dash Cams |
Specification
| Model Name | DR770X-2CH LTE |
| Memory Capacity | 64GB/256GB |
| Channel | 2CH |
| Highlights | Built-in 4G LTE, Sony STARVIS image sensors |
| Product Dimensions | Front: Black / Width 137.6 mm x Height 43 mm / 159 g Interior: Black / Width 67.4 mm x Height 25 mm / 25 g |
| Rear Camera Connection | Coaxial cable |
| Memory Support | microSD card up to 256GB |
| Recording Modes | Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected) * When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode |
| Parking Mode | Yes (hardwiring cable included) |
| Parking Mode Event Voice Notifications | Yes |
| Imaging Sensor | Front: Sony STARVIS CMOS Sensor (Approx. 2.1 M Pixel) Interior: Sony STARVIS CMOS Sensor (Approx. 2.1 M Pixel) |
| Viewing Angle | Front: Diagonal 139°, Horizontal 116°, Vertical 61° Interior: Diagonal 180°, Horizontal 150°, Vertical 93° |
| Resolution Frame Rate | Front / Interior Full HD (1920x1080) @60fps - Full HD (1920x1080) @30fps * Frame rate may vary during Wi-Fi streaming |
| Video Codec | H.264 (AVC) |
| Image Quality and Bitrate Front/Rear | Highest (Extreme): 25+10 Mbps Highest: 12+10 Mbps High: 10+8 Mbps Normal: 8+6 Mbps |
| Format Free | Yes (Adaptive) |
| Event File Overwrite Protection | Yes (up to 50) |
| SD Card Failure Alert | Yes |
| Scheduled Reboot | Yes |
| Video File Extension | MP4 |
| Wi-Fi | Built-in (802.11n (2.4~2.4835 GHz)) |
| Cloud Compatible | Yes |
| GPS | Build-in |
| Microphone | Built-in |
| Speaker | Built-in |
| Impact Sensor | 3-Axis Acceleration Sensor |
| LED Indicators | Front: REC LED, GPS LED, B/W /L LED, Front Security LED Interior: Interior Security LED |
| Rear Camera IR Illumination | 940 nm (4 Infrared (IR) LEDs) |
| Button | Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings |
| Operation Temperature | -20°C - 70°C (-4°F - 158°F) |
| Storage Temperature | -20°C - 70°C (-4°F - 158°F) |
| High Temp Cut Off | Approx. 80 °C (176 °F) |
| Backup Battery | Built-in supercapacitor |
| Input Power | DC 12V-24V (3 pole DC Plug(Ø3.5 x Ø1.1) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
| Power Consumption Hour | Normal Mode (GPS On/Cloud On): Avg. 470mA/12V Normal Mode (GPS On/Cloud Off): Avg. 410mA/12V Parking Mode (GPS Off/Cloud On): Avg. 370mA/12V Parking Mode (GPS Off/Cloud Off): Avg. 310mA/12V * Approx. 40mA increase in current when IR LEDs are ON * Actual power consumption may vary depending on use conditions and environment * Model DR770X-2CH IR LTE should be used only in circuits that satisfy Limited Power Source (Maximum power consumption is to be less than 100 VA or 8 A) |
| Certifications | Front: FCC, ISED, CE, UKCA, RCM, Telec, RoHS, WEEE, KC Interior: FCC, ISED, CE, UKCA, RCM, RoHS, WEEE, KC |
| Software | BlackVue Viewer * Windows 7 or higher, Mac Sierra OS X (10.12) or higher BlackVue Web Viewer * Chrome 71 or higher, Safari 13.0 or higher |
| Application | BlackVue Application * Android 8.0 or higher, iOS 13.0 or higher |
| Others | Built-in 4G LTE module compatible with Nano-SIM Frequency Bands: North America (NA version): B2, B4, B12 | Australia (AU version): B3, B5 | Japan (JP version): B1, B3, B18, B19 | Europe/Rest of world (GL version): B1, B3, B7, B20 |
| Bluetooth | Built-in (V2.1+EDR/4.2) |
| LTE | Built-in (SIM card not included) |
