AGM Sidewinder 20mK 12 Micron 384x288 50Hz Thermal Imaging Monocular
In Stock
AGM Global Vision

AGM Sidewinder 20mK 12 Micron 384x288 50Hz Thermal Imaging Monocular

Be the first to review the product Write a Review
$1,874.60 - $3,294.50
TM25-384
TM25-384
TM25-384
TM35-384
TM35-384
TM35-384
TM35-640
TM35-640
TM35-640
TM50-640
TM50-640
TM50-640
SKU:
AGM-3142451004SI21-VIRT
Current Stock:
$1,874.60
FREE Standard Delivery
30-Day Easy Returns
Secure Ordering

Frequently Bought Together:

TM25-384
Inc. Tax
Ex. Tax

Description

Features of AGM Sidewinder 20mK 12 Micron 384x288 50Hz Thermal Imaging Monocular

  • 12 micrometer, 384x288 / 640x512 resolution detector
  • Highest thermal sensitivity (NETD <20mK)
  • 64 GB memory module
  • 1x, 2x, 4x and 8x digital zoom
  • 50 Hz image frame rate

Product Info for AGM Sidewinder 20mK 12 Micron 384x288 50Hz Thermal Imaging Monocular

The Sidewinder is AGM's premium handheld observational thermal monocular series. All models come equipped with either a 384x288 / 640x512 twelve micron infrared detector and a 1024x768 OLED display, for improved color rendering.

GritrOutdoors is an authorized AGM Global Vision dealer

Details

Color:
Black
Activity:
Hunting, Outdoor
Product Type:
Monoculars

Specification

SKU 3142451004SI21 3142451005SI31 3142551005SI31 3142551006SI51
Palettes Black Hot, White Hot, Red Hot, Fusion Black Hot, White Hot, Red Hot, Fusion Black Hot, White Hot, Red Hot, Fusion Black Hot, White Hot, Red Hot, Fusion
Dimensions 188 × 58 × 65 mm (7.4 × 2.3 × 2.6 in) 188 × 58 × 65 mm (7.4 × 2.3 × 2.6 in) 188 × 58 × 65 mm (7.4 × 2.3 × 2.6 in) 200 × 78 × 68 mm (7.9 × 3.0 × 2.7 in)
Interface USB Type-C USB Type-C USB Type-C USB Type-C
Pixel Interval 12 μm 12 μm 12 μm 12 μm
Magnification 2× - 16× 3× - 24× 2× - 16× 2× - 16×
Detector type Vanadium Oxide Uncooled Focal Plane Array Vanadium Oxide Uncooled Focal Plane Array Vanadium Oxide Uncooled Focal Plane Array Vanadium Oxide Uncooled Focal Plane Array
Response Waveband 8μm to 14μm 8μm to 14μm 8μm to 14μm 8μm to 14μm
FFC (Flat Field Correction) Auto, Manual, External Correction Auto, Manual, External Correction Auto, Manual, External Correction Auto, Manual, External Correction
Highest Temperature Spot Tracking Yes Yes Yes Yes
Standby Mode Yes Yes Yes Yes
Refresh rate 50 Hz 50 Hz 50 Hz 50 Hz
Aperture F1.0
Detection Range (6' object) 1250 m 1800 m 1800 m 2600 m
NETD ≤ 20 mk (@25°C), F#=1.0
Resolution   384×288 640x512 640x512
Lens (focal length) 25 mm 35 mm 35 mm 50 mm
Power 5 VDC/2 A, 1.75 W 5 VDC/2 A, 1.75 W 5 VDC/2 A, 1.75 W 5 VDC/2 A, 1.75 W
Field of view (H × X) 10.5° × 7.9° 7.5° × 5.6° 12.5° × 10° 8.7° × 7°
Digital zoom 1×, 2×, 4×, 8× 1×, 2×, 4×, 8× 1×, 2×, 4×, 8× 1×, 2×, 4×, 8×
Diopter adjustment range -5 to +3 dpt -5 to +3 dpt -5 to +3 dpt -5 to +3 dpt
Monitor 1024×768, OLED 1024×768, OLED 1024×768, OLED 1024×768, OLED
Storage Built-in memory (64 GB) Built-in memory (64 GB) Built-in memory (64 GB) Built-in memory (64 GB)
Record Video Yes (on-board) Yes / Yes (on-board) Yes / Yes (on-board) Yes / Yes (on-board)
Capture Snapshot Yes Yes Yes Yes
Battery Type One 18650 Replaceable rechargeable Lithium battery One 18650 Replaceable rechargeable Lithium battery One 18650 Replaceable rechargeable Lithium battery One 18650 Replaceable rechargeable Lithium battery
Wi-Fi Yes Yes Yes Yes
Battery Operating Time Up to 7 hours Up to 7 hours Up to 7 hours Up to 7 hours
Weight 500 g (1.1 lb) 505 g (1.11 lb) 505 g (1.11 lb) 636 g (1.4 lb)
Working Temperature/ Humidity -30°C to 55°C (-22°F to 131°F) -30°C to 55°C (-22°F to 131°F) -30°C to 55°C (-22°F to 131°F) -30°C to 55°C (-22°F to 131°F)
Protection Level IP67 IP67 IP67 IP67
